FAST PMS

Power Management System

Fast Automatic Seamless Transfer

Nauti-Tech Systems proudly introduces the FAST-PMS, our all-in-one fully automated power management system. A revolutionary patent pending discrete switching technology operates lightning fast seamless transfers between sources without taking control of the generator's speed and voltage. This makes it easy to upgrade or retrofit any generator/shore power systems on small or large vessels. It works with all generator brand or type, including analog control models. It’s simple and economic to install and setup, it uses the existing contactors, or can be supplied with our complete switch gear module. It is also the perfect solution for a new built.



FAST PMS operates fully automated seamless transfers, starts & stops generators and switches to shore source when they become available. It also combines the shore cords to better balance the loads and manages polarity correction and safe disconnect.



With powerful features like, automatic load balancing, selective load shedding, KWH, frequency, current & voltage, events & alarms logging and monitoring. FAST PMS has it all! To complete this package, our daisy-chainable 7” inch touch screen provides quick and easy control, and can be integrated to your systems via Modbus or TCP/IP. The HMI shows the systems real time status, gives access to simple instant manual override and to a trove of adjustable settings and parameters used to finely tailor the automation, all at your finger tip. User defined presets can be stored and called back with a single touch, like “Away” “Fishing” “at Dock”.



FAST-PMS fully integrates with Nauti-Boost and Hubbell Marine transformers, and supports most of other isolation and/or boost transformers on the market. Versions are available for single phase, split phase and 3 phase installations

Accessories

Gen Start/Stop

Load Shedding

7inch Touch Display


Switchgear

Fast PMS Top View.png

SEAMLESS TRANSFER
  SHORE/GENS, GEN/GEN, SHORE/SHORE

Automated or manual lightning fast seamless transfer between sources. Thanks to our patent pending system, no need for generator voltage and speed controller. Works with any brand even analog control generators. Generator auto start/stop.


COMBINE SHORE CORDS A / B

Combines two shore cords into a single feed, balancing the load between both cords.


3 PHASE, OUT OF PHASE & PHASE REVERSE DETECTION/CORRECTION

Detection and automatic correction of dock phase miss-wiring, 3 phase distribution system detection and mitigation, out of phase detection and mitigation.


GENERATOR AUTO START/STOP

Automatically starts and stops generators on preset parameters all configurable by installer or user from the touch screen interface.

voltage control.png

NO NEED FOR GENERATOR SPEED/VOLTAGE CONTROLS

Works with any brand and type of generator, including models with analog controls. FAST PMS does not need to control the generator speed or voltage. It simplifies both installation and maintenance, making it affordable.


SAFE DISCONNECT

Safely disconnects shore cords and loads when system is not within safe operational limits.


LOAD BALANCING &
LOAD SHEDDING

Automated load balancing between sources, load shedding modules can be installed remotely and setup to temporarily disable non critical loads


VOLTAGE & CURRENT METERING
ALARM & EVENT LOGS

Current, voltage, frequency metering, alarm and events time stamped and logged.


POWERFUL FUNCTIONALITIES
AND EASY SETUP

FAST PMS has a modern touch screen interface allowing for easy setup and in depth configuration. User defined macros can trigger complex functionalities with the press of a single button. At anytime, the user can start a manual operation. The system safely pauses, completes the task before resuming to normal operation.
